Professional manufacturers HDPE perforated pipe

FOB Reference Price:Get Latest Price
$0.44 - $561.38 / Meters | 1000 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Erlang Shen
Model Number:
PE100
Material:
PE
Specification:
dn25mm-1200mm
Length:
On the request
Thickness:
en30.6mm-70.6mm
Standard:
GB/T13663-2000
Color:
Black with blue stripes
Supply Ability
Supply Ability:
80000 Meter/Meters per Month
Packaging & Delivery
Packaging Details
50 or 100 meters coil length,Other forms are also available upon request
Port
Qingdao or other agreed port
Lead Time :
18days after getting payment

Specifications

1.Manufacture
2.Material:hdpe100,hdpe80
3.Size:quantity of the holes can set
4.Standard:ISO4427
5.Joint:butt fusion or flang

Specifications

1.Manufacture
2.Material:hdpe100,hdpe80
3.Size:quantity of the holes can set
4.Standard:ISO4427
5.Joint:butt fusion or flang





PE100 Water Pipe

1.Material:PE100
2.Pressure Rating: 0.6 MPa, 0.8 MPa, 1.0MPa, 1.25 MPa, 1.6MPa
3.Size:dn800mm-dn1200mm
4.Standard:ISO4427:2007,GB/T13663-2000,BS EN12201:2003
5.Colors:Black with blue stripes,Other colors are also available upon request
6.Form Supplied: 50 or 100 meters coil length,Other forms are also available upon request

Detailed Description

1. Non-toxic: no heavy metal additives ,would not be covered with dirt or contaminated by bacterium

2.Low Flow Resistance: smooth interior walls and low friction

3.Corrosion Resistant: resist chemical matters and electron chemical corrosion

4. Various Joint Availability: socket fusion joint, butt fusion joint, electro fusion joint and transition joint

5. Easy installation: light weight and handed friendly

6.Longevity: more than 50 years under proper use

7.Excellent Flexibility: can be supplied in coil

Applications

1.Industrial liquids transportation

2.Sewage treatment

Physical Properties

Properties

Typical Value

Specific Gravity, g/cm3(20°C)

0.941~0.965

Longitudinal Reversion, %(110°C)

≤3

Oxidation Induction Time, min(200°C)

≥20

Extension Rate at Break,%

≥350

Hydraulic Pressure Test (PE100)

20°C,100h, Hoop Stress is 12.4MPa

No Failure

80°C,165h, Hoop Stress is 5.5MPa

No Failure

80°C,1000h,Hoop Stress is 5.0MPa

No Failure
